ArcticPRO® ACX 310 is the perfect compact solution for mobile or secondary A/C service. Weighing only 65 kg, it delivers premium functionality for R134a systems in a space-saving design.
Powered by MAHLE’s E³ technology, the ACX 310 ensures ecological, economical, and efficient servicing. Workshops benefit from integrated remote support, an intuitive interface, and advanced reporting capabilities—all backed by a European-wide service network.
Key Features
| E³ Functions |
E³ – FILL | E³ – PUMP |
| Display |
B&W 35x200, 4 lines / 30 characters |
| Keypad |
4 direction keys, Enter, Esc |
| Service Database |
Supports R134a | ACX 310 |
| Activation |
Via mobile App |
| Non-condensable Gas |
Automatic check / manual release |
| Oil Bottles |
2 (fresh & used) |
| Remote Assistance |
Via ACX Manager (USB) |
Technical Specifications
| Refrigerant |
R134a |
| Refrigerant Tank |
12 Liters |
| Compressor |
8cc |
| Filter Drier Capacity |
75 kg |
| Recovery Rate |
>95% |
| Pressure Sensors |
LP |
| Operating Temp |
10°C to 50°C |
| Power Supply |
1Ph, 230V, 50Hz, 800W |
| Hose Length |
3 meters |
| Menu Languages |
25 |
| Certifications |
CE, PED |
Key Highlights
- MAHLE E³ Technology: Ecological, Economical, Efficient
- Compact & lightweight (65 kg) – ideal for mobile use
- Automatic & manual non-condensable gas purge
- Manual mode with hose length compensation
- 10-minute A/C system performance test with report
- Hybrid vehicle compatible
- Integrated vehicle database + PDF report export (USB)
- Optional thermal printer, refrigerant analyzer & nitrogen leak test
- Remote service support via ACX Manager
