MAHLE ArcticPRO® ACX 350 is a fully automatic A/C service station that meets the highest professional standards for refrigerant recovery, recycling, and recharging. Built for both R134a and convertible to R1234yf, it’s a future-proof solution for workshops handling a high volume of vehicles, including hybrids.
Equipped with MAHLE’s E³ technology (Ecological, Economical, Efficient), the ACX 350 combines fast service cycles with intuitive control via a 7” TFT touchscreen. The system features full automation, optional gas analysis, and wireless connectivity for remote diagnostics and reporting.
Key Features
| E³ Functions |
E³ – FILL | E³ – PUMP | E³ – CONNECT |
| Display |
7” high visibility TFT touchscreen |
| Door System |
One-Touch liftdoor |
| Service Data |
Built-in vehicle database |
| Gas Purge System |
Fully automatic air purge |
| Oil Bottles |
3 + 1 (PAG, used, UV additive, POE) |
| Remote Assistance |
RE.SOLVE via WiFi |
| Print & Report |
USB + PC (Windows) network printout |
Technical Specifications
| Refrigerant |
R134a (R1234yf with optional kit) |
| Refrigerant Tank |
20 Liters |
| Compressor |
14cc |
| Filter Drier Capacity |
150 kg |
| Recovery Rate |
>95% |
| Pressure Sensors |
Tank, LP, HP |
| Oil Scales |
2 (fresh & used) |
| Operating Temp |
10°C to 50°C |
| Power Supply |
1Ph, 230V, 50Hz, 800W |
| Hose Length |
4.5 meters |
| Menu Languages |
25 |
| Certifications |
CE, PED |
Key Highlights
- Fully automatic non-condensable gas purge system
- Manual operation mode and automatic hose compensation
- 10-minute A/C performance test with customer report
- Hybrid vehicle compatible with electronic car database
- Status indicator lights for operational clarity
- Network printing capability via PC
- Convertible to R1234yf (optional kit)
- Optional Features:
- Thermal Printer
- Refrigerant Analyzer
- Forming Gas Leak Test (requires connector)
- Nitrogen Leak Test (enabled via GoLive)
